Yamaha MGX12V B- 18-Channel Digital Mixing Console, Black

Yamaha MGX12V B - 18-Channel Digital Mixing Console, Black

The MGX12V builds on Yamaha’s MG legacy with a compact digital mixing console that seamlessly integrates audio and video. In addition to superb sound quality, versatile I/O,
and intuitive touch-panel operation, it features a USB-HDMI interface with capture and pass-through, enabling simultaneous high-definition video and audio streaming or recording. With four microphone inputs and four headphone outputs, it is especially
well-suited for podcast production with multiple participants, as well as live sound, installed systems, and content creation. Designed for creators, engineers, and performers, the MGX12V elevates production quality and expands creative possibilities
across diverse applications.

Features:

• 11 + 1 fader configuration (non-motorized fader)
• A 4.3-inch touchscreen with five control knobs
• Input mixing channels: 4 mono + 4 stereo + 1 Sound Pad + 2FX return
• Busses: 8 Mix + 2FX + 1 CUE + 1 STEREO
• Local I/O: 8 Mic/Line (4 XLR/TRS Phone Combo), 8 Line (4 TRS Phone, 4 RCA) inputs,
and 2 XLR, 6 TRS Phone, 4 Headphones
• USB MAIN: 18 inputs / 18 outputs (32-bit / 96 kHz)
• USB SUB: 2 inputs / 2 outputs (16-bit / 48kHz)
• Bluetooth Audio Input: 2 inputs (Bluetooth 5.0, A2DP)
• microSD Card: 16-track recording / 2-track playback (24-bit / Up to 96 kHz)
• HDMI-to-USB video/audio input with capture function and real-time HDMI
passthrough
• Built-in DSP processor for professional sound and latency-free monitoring
• Assistive features: Auto Gain, Clip Safe, Simple/Standard mode, Scene Recall
• Included accessories: Start Guide, Safety Guide, Steinberg Software License Card
(Cubase AI, WaveLab Cast LE, Basic FX Suite, Steinberg Plus), AC Power Adapter (PA-
300C)
